| Condensing Units |
| Model Number |
Capacity |
Refrigerant |
Unit Type |
Compressor Type |
Nominal Efficiency |
Documents |
| YC3 |
1.5 - 5 Tons |
R-454B |
Vertical Discharge |
Single Stage |
13.4 SEER2 |
Technical Guide |
| YC4 |
1.5 - 5 Tons |
R-454B |
Vertical Discharge |
Single Stage |
14.3 SEER2 |
Technical Guide |
| YC6 | 1.5 - 5 Tons |
R-454B |
Vertical Discharge |
Two Stage (Except 1.5 Tons) |
16 SEER2 |
Technical Guide |
| YC2E |
1.5 - 5 Tons |
R-410A |
Vertical Discharge |
Single Stage |
14.3 SEER2 |
Technical Guide |
| YC2F |
1.5 - 5 Tons |
R-410A |
Vertical Discharge |
Single Stage |
15.2 SEER2 |
Technical Guide |
| HMCG2 |
2 - 5 Tons |
R-410A |
Horizontal Discharge |
Inverter Driven |
16.0 SEER2 |
Technical Guide |
| YXT |
2 - 5 Tons |
R-410A |
Vertical Discharge |
Dual Stage |
19 SEER |
Technical Guide |
| YXV |
2 - 5 Tons |
R-410A |
Vertical Discharge |
Inverter Driven |
Up to 20 SEER |
Technical Guide |
| TCD2 (3 Phase) |
2.5 - 5 Tons |
R-410A |
Vertical Discharge |
Single Stage |
13.4 SEER2 |
Technical Guide |
| Ask us about our current stock of R-410A units |
|
| Heat Pump Condensing Units |
| Model Number |
Capacity |
Refrigerant |
Unit Type |
Compressor |
Nominal Efficiency |
Documents |
| YH4 |
1.5 - 5 Tons |
R-454B |
Vertical Discharge |
Two Stage (Except 1.5 Tons) |
14.3 SEER2 |
Technical Guide |
| YH5 |
1.5 - 5 Tons |
R-454B |
Vertical Discharge |
Two Stage (Except 1.5 Tons) |
15.2 SEER2 |
Technical Guide |
| YH6 |
2 - 5 Tons |
R-454B |
Vertical Discharge |
Two Stage |
16 SEER2 |
Technical Guide |
| HH8 |
2 - 5 Tons |
R-454B |
Horizontal Discharge |
Inverter Driven |
18 SEER2 |
Technical Guide |
| YH2E |
1.5 - 5 Tons |
R-410A |
Vertical Discharge |
Dual Stage |
14.3 SEER2 |
Technical Guide |
| YH2F |
1.5 - 5 Tons |
R-410A |
Vertical Discharge |
Dual Stage |
15.2 SEER2 |
Technical Guide |
| HMH72 |
2 - 5 Tons |
R-410A |
Horizontal Discharge |
Inverter Driven |
17 SEER |
Technical Guide |
| YZT |
2 - 5 Tons |
R-410A |
Vertical Discharge |
Dual Stage |
19 SEER |
Technical Guide |
| YZV |
2 - 5 Tons |
R-410A |
Vertical Discharge |
Inverter Driven |
Up to 20 SEER |
Technical Guide |
| THE (3 Phase) |
2.5 - 5 Tons |
R-410A |
Vertical Discharge |
Single Stage |
14 SEER |
Technical Guide |
| Ask us about our current stock of R-410A units |
|
| Ultra-Low NOx Furnaces |
| Model Number |
Capacity |
Motor Type |
Gas Valve Type |
AFUE |
Documents |
| TL8E |
60 - 100 MBH |
ECM, 5 Speed |
Single Stage |
80% |
Technical Guide |
| TL9E |
60 - 100 MBH |
ECM, 5 Speed |
Single Stage |
95% |
Technical Guide |
Mixing box with economizer and CO2/DCV (Demand Controlled Ventilation) controls available for all furnaces.
|
| Low NOx Furnaces |
|
Mixing box with economizer and CO2/DCV (Demand Controlled Ventilation) controls available for all furnaces.
|
| Fan Coils |
| Model Number |
Capacity |
Motor Type |
Description |
Documents |
| ADP AX |
2 - 5 Tons |
ECM, 5 Speed |
Multiposition, Single Cabinet |
Technical Guide |
| ADP AV |
2 - 5 Tons |
ECM, Variable |
Multiposition, Single Cabinet |
Technical Guide |
| JHET |
1.5 - 5 Tons |
ECM, 5 Speed |
Multiposition, Single Cabinet |
Technical Guide |
| JHVT |
1.5 - 5 Tons |
ECM, Variable |
Multiposition, Single Cabinet |
Technical Guide |
| JMET |
2 - 5 Tons |
ECM, Variable |
Multiposition, Modular |
Technical Guide |
| JMVT |
2 - 5 Tons |
ECM, Variable |
Multiposition, Modular |
Technical Guide |
Mixing box with economizer and CO2/DCV (demand controlled ventilation) controls available for all fan coils.
|
| Low Profile Fan Coils (SunTherm, 11" High) |
| Model Number |
Capacity |
System Description |
AHRI Certificate |
Documents |
| CEHX-19-00-ED-1C80 |
1.5 Tons |
14.3 SEER2 with YH2E18 Heat Pump |
210929454 |
Technical Guide |
| CEHX-24-00-ED-1C80 |
2 Tons |
14.3 SEER2 with YH2E24 Heat Pump |
210720888 |
|
| CEHX-35-00-ED-1C81 |
2.5 Tons |
14.3 SEER2 with YH2E30 Heat Pump |
210720741 |
|
| CEHX-37-00-ED-1C81 |
3 Tons |
14.3 SEER2 with YH2E36 Heat Pump |
210720742 |
|
| CEHX-19-00-ED-1C80 |
1.5 Tons |
16.0 SEER2 with YH2F18 Heat Pump |
210613578 |
|
| CEHX-25-00-ED-1C81 |
2 Tons |
15.2 SEER2 with YH2F24 Heat Pump |
210613576 |
|
| CEHX-35-00-ED-1C81 |
2.5 tons |
15.2 SEER2 with YH2F30 Heat Pump |
210613574 |
|
| CEHX-37-00-ED-1C81 |
3 Tons |
15.2 SEER2 with YH2F36 Heat Pump |
210613572 |
|
|
| Low Profile, Uncased Fan Coils (ADP, 10.5" High) |
| Model Number |
Capacity |
System Description |
AHRI Certificate |
Documents |
| ADP AC190*T |
1.5 Tons |
14.3 SEER2 with YH2E18 Heat Pump |
211135172 |
Technical Guide |
| ADP AC250*T |
2 Tons |
14.3 SEER2 with YH2E24 Heat Pump |
211271827 |
| ADP AC310*T |
2.5 Tons |
14.3 SEER2 with YH2E30 Heat Pump |
211272653 |
|
|
